Factory Supply 0-80 Degree Gas Water Heater Thermostat for Sell

Model NO. : SNT-6011

Temperature Resistance : Max. 320ºC

Insulation Resistance : >100mΩ

Appliance : Gas Oven, Gas/ Outdoor Heaters

Tolerance Range : 3~12ºC

Gas Source : Ng/LPG/Propane/Butane

Switch Apllication : Appliance Accessories

Dielectric Strength : 2000V. AC 1min

Transport Package : Standard Carton and Customized Packing

Specification : Customized

Trademark : Sinopts

Origin : China

Supply Ability : 500000piece/Year

Certification : ISO9001, CE, CSA

Type : Gas Water Heater Parts

Material : Al

Form : Customized

Shape : Customized

Warranty : 1 Year

Samples : US$ 35/Piece 1 Piece(Min.Order) | Request Sample

Customization : Available | Customized Request

Contact Now

Product Description

Product Application

Multifunctional safety gas controls valve are suitable for heaters and other appliances which require manual control at two flow levels.

Main Features

1) Thermoelectric flame supervision device with restart interlock.

2) Pilot gas rate adjuster.

3) With inlet and outlet pressure test points

4) Max capacity can be 5.0CBM/hours.

TECHNICAL SPECIFICATIONS
main gas connection	Rp1/2 or Rp3/8	usage gas	All gas
thermocouple connection	M9X1, M10X1	max gas inlet pressure	50 mbar
outlet pressure setting range	3-18mbar	flange fixing holes	M4X7
working temperature range	0-80ºC	mounting holes	5.0 diameter
pilot outlet	M10X1

Factory Supply 0-80 Degree Gas Water Heater Thermostat for Sell

Looking forward to cooperating with each other sincerely and develop together on the basis of the quality first, honest treatment and mutual benefits.

Factory Supply 0-80 Degree Gas Water Heater Thermostat for Sell Images
